First Class Advanced Anemometer-Heated

Make: Thies Clima                                        Model: 4.3351.00.000
✅ The wind transmitter is designed for the acquisition of the horizontal component of the wind speed in the field of meteorology and environmental measuring technology.(With heating option  (24V AC/DC, 25W))
✅ Measurand : Wind Speed.
✅ Sensor Type : Cup Anemometer
✅ Signal Output : Frequency (1082Hz @ 50m/s)
✅ Supplied With : Terminal plug, Instruction for Use, Factory test/ Calibration Certificates.


First Class Advanced Anemometer-Heated: 4.3351.00.000 (Thies clima)

The anemometer is made for the measurement of the capacity characteristics of wind power systems, the evaluation of location, and the acquisition of the horizontal component of wind velocity in the fields of meteorology and environmental measuring technology. Every criterion of IEC 61400-12-1 (2005-12) for an instrument of accuracy class 0.5 is satisfied by the anemometer.

Special characters are developed and optimized for dynamic behavior at low beginning value, less overspeeding, and strong turbulence intensity. The output contains a digital signal that represents the measurement value. It can be sent to process control systems, data loggers, display instruments, recording instruments, and data loggers.

It has an electrically controlled heater that ensures the ball bearings work smoothly and keeps the shaft and slot from freezing up during winter operation.

Application and features of First Class Advanced Anemometer-Heated:

Application

Features

✅ Power curve measurement at wind power plants
✅ Wind potential studies
✅ Site appraisals
✅ Research purposes
✅ Meteorological Applications
✅ Class A compliance in accordance to IEC 61400-12-1 and 61400-12-1 Ed.2
✅ Worldwide the only Class S 0.5 anemometer according IEC 61400-12-1 Ed.1 & Ed.2, ISO 17713-1, MEASNET
✅ Calibrated according to MEASNET and IEC 61400-12-1 Ed.2 (ilac-MRA)
✅ Frequency output (1082 Hz at 50 m/s)
✅ Supply 3.3 … 42 V DC
✅ Permissible Ambient conditions: -50 °C … 80 °C
✅ With heating (24V AC/DC, 25W)
✅ Measurement Range: 0.3…75 m/s
✅ Accuracy: 1% of value or <0.2 m/s (0.3…50m/s)
✅ Survival Wind Speed 80 m/s (≥ 30 min)
✅ Linearity: r>0.99999 (4…20 m/s)
✅ IP 55
✅ 2 years warranty
Make

Thies Clima

Model

4.3351.00.000

Weight (Mass)

approx. 0.5kg

Dimension

290 x 240 mm

Outputs

Form : rectangle, edge steepness < 1μsec
Frequency : 1082Hz @ 50m/s
Amplitude : is supply voltage, max. 15V
Push-Pull Output : output resistance: typical 100Ω ≥ 10V, 130Ω @ 5V, 230Ω @ 3.3V, Constant power limiting on typical 25mA
Load : R ≥ 1kΩ, C ≤ 200nF (corresp. to length typical cable < 1km)

Power Supply

Electrical supply for opto-electronic scanning :
Voltage: 3.3…48V DC (galvanic isolation from housing)
Current: 130μA typ. 150μA max. @ 3,3V bis 15,0V (w/o external load) , 180μA typ. 200μA max. @ 15V bis 48V (w/o external load)
Electrical supply for heating :
Voltage : 24V AC/DC +- 20%, 45…65 Hz (galvanic isolation from housing)
Idling voltage : max. 32V AC and max. 48V DC
Capacity : 25W

Operating Environment

Permissible Ambient conditions : – 50…+ 80°C, all occurring situations of relative humidity (incl. dew moistening)

Protection Level

IP 55 (DIN 40050)

Standerd / Regulation

IEC 61400-12-1 (2005-12), ISO 17713-1, Measnet

Mast Diameter

Mounting on mast :
Outer diameter : ≤ 34mm
Inner diameter : ≥ 22mm
Note: mounting on mast is possible with separate adapter (option)

Wind Speed

Survival speed : 80m/s (min. 30 minutes)
