Thies Compact: 4.3520.00.000-Heated

Thies Compact: 4.3520.00.000-Heated

Thies Compact: 4.3520.10.000-unheated WindSensor Anemometer: P2546A OPR

Make: Thies Clima                                      Model: 4.3520.00.000-Heated
✅ Measuring transmitter for the measurement of the horizontal wind velocity with frequency output.
✅ Measurand : Wind Speed.
✅ Sensor Type : Cup Anemometer
✅ Signal Output : Frequency output (2 – 573 Hz)
✅ Supplied With : 5m Cable, Factory test/ Calibration Certificates.
Ask For Quotation
Category:

Thies Compact: 4.3520.00.000-Heated:

Measuring transmitter with frequency output for measuring horizontal wind velocity (active signal). Appropriate for data loggers the housing is constructed of plastic and anodized aluminum, while the cup star is made of plastic. The instrument contains two nuts for attachment and a threaded pin (PG 21).

Application and features of Thies Compact: 4.3520.00.000-Heated:

Application

Features
✅ Building services engineering
✅ Research Industry
✅ Wind power plants
✅ Environmental technology
✅ Warning systems		 ✅ Measurement Range: 0.5…50 m/s
✅ Accuracy: ± 0.5 m/s or 3% of measurement value
✅ Resolution: 0.1 m/s
✅ Frequency output (2 – 573 Hz)
✅ Supply 15 … 28 V DC
✅ With heating (24 V AC / DC, 20W)
✅ Opto-electronic principle
✅ Current Supply: 20 mA
✅ Survival Wind Speed 80 m/s (≥ 30 min)
✅ Ambient Temp.: -40 … +70 °C
✅ IP 55
✅ 2 years warranty
Make

Thies Clima
Model

4.3520.00.000
Outputs

Frequency output : (2 – 573 Hz)
Power Supply

15 … 28 V DC
Heating :10-28 V DC
Operating Environment

-40 … +70 °C
Protection Level

IP 55
Wind Speed

Measuring range : 0.5 … 50 m/s
Resolution : < 0.1 m/s
Accuracy : ±3 % of meas. value or ± 0.5 m/s
