Long term stability of PV modules can be evaluated with the multi channel MP-160 system. I-V characteristics of multiple PV cells and modules can be measured individually. MI-510 module selector provides 6 channels to measure the PV modules sequentially. In total 4 units of the MI-510 can be connected to the MP-160 and 4 units to the MP-180.
- PV cells and modules up to 300W
- Switching capacity 100V / 7A
- 6 input channels
- Up to 4 module selectors
Make: Eko
Measurement range Voltage | 0.05 – 300 V |
---|---|
Measurement range Current | 0.005 – 7 A |
Measurement range Power | 0 – 300 W |
Operating temperature range | 0 – 40 °C |
Power supply | 100 – 240 VAC, 30W |
Dimensions mm | 370 (W) x 350 (D) x 133 (H) |
Weight | 5 kg |
Ingress protection IP | – |
Input channels # | 6 |
Max. devices # | 4 |
