HygroClip XD Industrial probe

Make: Rotronic                                    Model: HygroClip XD (Industrial probe)
✅ The HygroClip XD is available as industrial probe with remote sensor.
✅ Measurand: Relative humidity & temperature
✅ Sensor Type: Temperature probe
✅ Signal Output: Analog (voltage / current), digital (UART / RS-485)
✅ Supplied With: Cable, Factory test/ Calibration Certificates
Category:

The HygroClip XD Industrial probe is a high-precision humidity and temperature sensor that is specifically designed for use in industrial environments. The probe is made from durable materials that are resistant to corrosion and can withstand high temperatures and pressures. The HygroClip XD also features a protective housing that helps to prevent damage from vibration, dust, and other environmental factors.

One of the key features of the HygroClip XD is its high accuracy and repeatability. The sensor is able to measure humidity with an accuracy of <1 %RH / year and temperature with an accuracy of 23 °C. This makes it ideal for use in applications where precision is critical, such as in industrial process control or quality control. The sensor also features a fast response time, allowing it to quickly adapt to changes in humidity and temperature.

The HygroClip XD Industrial probe has a wide measurement range of humidity and temperature, which makes it suitable for use in various environments. The probe can measure humidity between 0-100%RH and temperature between -40°C and +85°C, which makes it ideal for use in a wide range of industrial applications, such as in HVAC systems, warehouses, clean rooms, laboratories, and more.

The HygroClip XD Industrial probe is easy to install and maintain. The sensor comes with an integrated connector that allows for quick and easy installation, and it is also designed for easy calibration. The sensor is also designed for easy maintenance and can be cleaned and serviced without the need for special tools or equipment.

In summary, The HygroClip XD is a highly accurate and reliable humidity and temperature sensor that is designed for use in industrial environments. Its durable design and wide measurement range make it suitable for use in a variety of applications, while its high accuracy and fast response time make it ideal for use in applications where precision is critical. Its ease of installation and maintenance make it an ideal choice for industrial and commercial use.

The HygroClip XD is available as a standard probe or as an industrial probe with a remote sensor. The standard versions come in the colors black or white.

Application and features of HygroClip XD Industrial probe:

Application

Features

✅ Process and climate technology
✅ Agriculture, stables
✅ Incubators, hatchers
✅ Outdoor temperature measurement
✅ Storage rooms, cooling chambers
✅ Measures relative humidity & temperature
✅ Calculates dew/frost point
✅ Power supply range: 5…16 VAC / 5…24 VDC
✅ Outputs:0…1 V / 0…5 V / 0…10 V / 0…20 mA / 4…20 mA
✅ Voltage outputs configurable via software
✅ Highest precision and reproducibility
✅ Excellent long-term stability <1 %RH / year
✅ Digital interface for calibration and measurement processing
Make

Rotronic

Model

HygroClip XD (Standard probe)

Dimension

Dimensions probe head: Diameter: ∅ 15 mm
Length: 100 mm / 250 mm, 400 mm / 550 mm / 700 mm

Power Supply

5…16 VAC / 5…24 VDC (0…1 V) ,12…16 VAC / 16…24 VDC (all kind of output signals)

Measuring range

-100…+200 °C * / 0…100 %RH *Short-term peak load

Outputs

Analog (voltage / current), digital (UART / RS-485)

Power Consumption

7 mA (typical) @ 24 VDC, 0…10 V, 12 mA (typical) @ 5 VDC, 0…1 V

Operating Environment

-40…+85 °C / 0…100 %RH

Protection Level

IP65

Relative Humidity

Humidity sensor: ROTRONIC HYGROMER® IN-1
Long-term stability, humidity sensor: <1 %RH / year

Temperature

Temperature sensor: Pt100 1/3 Class B
Accuracy at 23 °C, < 1 mV (1 V) / <10 mV (10 V) / <20 μA
Response time τ63P: <15 s
Accuracy at 23 °C, ± 5 K: 0.8 %RH / 0.2 K @ 5…24 VDC , Adjusted at 23 °C and 10, 35, 80 %RH @ 5 VDC

Material

Conformities / Housing: CE / EMC compatibility: CE conformant 2007/108/EG, FDA / GAMP conformity: 21 CFR Part 11 / GAMP 5, Housing material: PEEK

Quote HygroClip XD Industrial probe
