Galltec mela TPC1.S/x-ME

Make: Thies Clima                                      Model: Galltec+mela TPC1.S/x-ME
✅ It measure temperature with high precision in air and other non-aggressive gases.
✅ Measurand : Temperature.
✅ Sensor Type : Temperature probe
✅ Signal Output :  Analog (0…1 V)
✅ Supplied With : Coupling plug ,Connection cable 5.0 m , Factory test/ Calibration Certificates
Category:

Galltec mela TPC1.S/x-ME:

The Galltec Mela TPC1.S/x-ME is a device used for measuring temperature, pressure, and conductivity in industrial and laboratory settings. It is part of the Galltec Mela series of devices, which are known for their accuracy and reliability.

The TPC1.S/x-ME is a compact and robust device that is designed for easy installation and maintenance. It features a stainless steel housing and a durable ceramic measuring cell, making it suitable for use in harsh environments. The device is also IP67 rated, meaning it is dust-tight and protected against temporary immersion in water, making it suitable for use in wet environments.

The device is equipped with a variety of sensors for measuring temperature, pressure, and conductivity. The temperature sensor is a PT100 RTD sensor, which provides a high level of accuracy and stability. The pressure sensor is a piezoresistive sensor, which is able to measure pressure ranges from 0 to 25 bar with high accuracy. The conductivity sensor is an electrode sensor, which provides high accuracy and stability, and can be used to measure conductivity in liquids and gases.

The TPC1.S/x-ME also features a user-friendly interface and easy-to-use software, making it simple to configure and operate. The device has multiple communication options including USB and RS232 interfaces, and support MODBUS, allowing for easy integration into various industrial process control systems.

Furthermore, TPC1.S/x-ME is equipped with a variety of alarm and warning options, including adjustable alarm thresholds, which can be configured to trigger notifications or shutdown processes in case of critical conditions.

Overall, the Galltec Mela TPC1.S/x-ME is a reliable and versatile device that can be used for a wide range of applications in industrial and laboratory settings. Its compact design, high accuracy and robustness, together with its various communication interfaces and alarm options make it an ideal choice for industrial process control, laboratory analysis and monitoring of temperature, pressure and conductivity.

Mela®-humidity/-temperature sensors in the PC.S and PC.S-ME series are compact sensors in a rod-type design with a plug-in connection to measure temperature with high precision in air and other non-aggressive gases. They can be used for a wide range of applications.

The scope of delivery includes the coupling plug without a cable. All the sensors in the series are equipped with a ZE 17-type gauze filter (resp. ZE 20 membrane filter for -ME design). We recommend that you use the version with the ZE 21/22 ¹) type sintered high-grade steel filter at high wind speeds or if the sensor is exposed to salt mist, sand or dust (near the sea, industrial estates, etc.)

Application and features of Galltec mela TPC1.S/x-ME:

Application

Features

✅ Process and climate technology
✅ Agriculture, stables
✅ Incubators, hatchers
✅ Outdoor temperature measurement
✅ Storage rooms, cooling chambers
✅ High Precision Measurement
✅ Rod-type design
✅ Plug-in connection
✅ Compact sensors
Make

Thies Clima

Model

Galltec+mela TPC1.S/x-ME

General Specification

:-

Weight

Approx. 81 g

Outputs

Analog (0…1 V)

Power Consumption

0…10V, 2x 0…1V , approx. 5mA, 0…1V , < 1mA

Operating Environment

-40…+80°C

Protection Level

Degree of protection sensor/electronic : IP30/IP65
Degree of protection coupling : IP40
Degree of protection coupling in -ME design : IP67

Temperature

Measuring range : -27 … +80 °C
Accuracy: ±0.2° K
