Galltec mela KPC1.S/6-ME

Make: Thies Clima                                      Model: Galltec+mela KPC1.S/6-ME
✅ It measure relative humidity and temperature with high precision in air and other non-aggressive gases.
✅ Measurand : Relative Humidity and Temperature.
✅ Sensor Type : Temperature probe
✅ Signal Output : Analog (2 x 0…1 V)
✅ Supplied With: Coupling plug without a cable, Factory test/ Calibration Certificates.
Category:

Galltec mela KPC1.S/6-ME:

The Galltec Mela KPC1.S/6-ME is a programmable controller designed for industrial automation applications. It is a compact, modular controller that can be configured to control a wide range of industrial processes.

One of the key features of the KPC1.S/6-ME is its ability to handle a large number of I/O points. It has 6 digital inputs and 6 digital outputs, as well as 2 analog inputs and 2 analog outputs. This allows the controller to handle a wide range of process variables, such as temperature, pressure, and flow.

The controller also has a built-in Ethernet interface, which allows it to communicate with other devices on a network. This makes it easy to integrate the controller into an existing automation system, or to connect it to a remote monitoring or control system. Additionally, it has serial communication ports, which can be used to connect to various devices like PLCs, SCADA systems, and HMIs.

The KPC1.S/6-ME is also equipped with a powerful microprocessor, which allows it to handle complex control algorithms and logic. This can be especially useful in applications that require advanced control strategies, such as PID control or advanced process sequencing. Additionally, the controller has a built-in real-time clock, which can be used to schedule and automate certain tasks or processes.

The controller has a user-friendly interface, which allows users to easily program and configure the controller. It comes with a software development kit, which can be used to create custom programs and applications. The software development kit supports several programming languages such as C, C++, Java and Python.

Overall, the Galltec Mela KPC1.S/6-ME is a versatile, powerful programmable controller that is well-suited for a wide range of industrial automation applications. Its compact size, large number of I/O points, and built-in Ethernet and serial communication interfaces make it easy to integrate into existing systems, while its powerful microprocessor and built-in real-time clock allow it to handle advanced control algorithms and automate tasks.

Galltec+mela KPC1.S/6-ME: Mela®-humidity/-temperature sensors in the PC.S and PC.S-ME series are compact sensors in a rod-type design with a plug-in connection to measure relative humidity and temperature (individually or together ) with high precision in air and other non-aggressive gases. They can be used for a wide range of applications.

The scope of delivery includes the coupling plug without a cable. All the sensors in the series are equipped with a ZE 17-type gauze filter (resp. ZE 20 membrane filter for -ME design). We recommend that you use the version with the ZE 21/22 ¹) type sintered high-grade steel filter at high wind speeds or if the sensor is exposed to salt mist, sand or dust (near the sea, industrial estates, etc.). In the …/9 series the humidity sensor element is directly protected by a PTFE filter. The advantage of this is the improved temperature dynamics, in particular at low air speeds. In the …./9-ME series a glass Pt-100 is used.

Application and features of Galltec mela KPC1.S/6-ME:

Application

Features

✅ Process and climate technology
✅ Agriculture, stables
✅ Incubators, hatchers
✅ Outdoor temperature measurement
✅ Storage rooms, cooling chambers
✅ High precision Measurement
✅ Rod-type design
✅ Plug-in connection
✅ Compact sensors
Make

Thies Clima

Model

Galltec+mela KPC1.S/6-ME

General Specification

:-

Weight

Approx. 81 g

Outputs

Analog (2 x 0…1 V)

Power Consumption

0…10V, 2x 0…1V , approx. 5mA, 0…1V , < 1mA

Operating Environment

-40…+80°C

Protection Level

Degree of protection sensor/electronic ………… IP30/IP65
Degree of protection coupling ……………………………… IP40
Degree of protection coupling in -ME design …………… IP67

Temperature

Measuring range : -30…+70°C
Accuracy: ±0.2° K

Relative Humidity

Measuring range : 0…100% rh
Accuracy : ±2% rH
