Meteo-40S Plus-Data Logger

Make: Ammonit                                        Model: Meteo-40S Plus
✅ Wind and Solar Resource Assessment + Wind Farm Monitoring (SCADA) + Power Performance Measurements
✅ Compliant with IEC 61400-12-1:2017
✅ User-friendly configuration via protected web interface
✅ Various inputs and outputs for different measurement purposes

Category:

Meteo-40S Plus-Data Logger:

Ammonit Meteo-40 data recorders are professional measurement equipment that captures meteorological parameters in order to determine a site’s wind energy potential. The data loggers are adaptable and suitable for a wide range of applications. The applied measurement assessment and data security standards fulfill the needs of expert professionals. However, the user-friendly web interface allows you to easily arrange sensors, data, and communication.

Meteo-40 satisfies the most stringent data security and quality standards. Use Meteo-40 for your measurement campaign to ensure traceable and transparent measurement data from recording to data processing. In terms of data authenticity and integrity, your campaign will adhere to the German TR6 Rev. 9 and the MEASNET criteria.

Compliant with IEC 61400-12-1:2017
User-friendly configuration via protected web interface
Various inputs and outputs for different measurement purposes

New developments:

  • LTE and 4G modems e. g., PLS8-E and many more.
  • Web Interface and Email: TLS 1.1, 1.2, and 1.3 are supported.
  • Admin user can create new users or delete them.
  • Predefined users can be deleted
  • Less latency in SCADA systems due to faster Modbus RTU and TCP
  • Latest Linux version and newest versions of security libraries like SSL, SSH, SFTP, SCP, https, etc.
  • Data can be sent with FTPS which makes industry standard encryption more accessible.

Advantages:

  • Data verification using diagrams and curves
  • Data plausibility check with customizable filters
  • Checking data completeness with a calendar
  • Campaign documentation in PDF reports
  • Efficient problem detection
  • Configurable alert messages, e.g., low power supply
  • Configurable data exports for further data processing
  • Certified data files and encrypted data transfer

Application and features of Meteo-40S Plus-Data Logger:

Application

Features

✅ Wind Resource Assessment
✅ Power Performance Measurements
✅ Wind Park Monitoring / SCADA
✅ Wind Measurement in Cold Climate
✅ Solar Resource Assessment
✅ Soiling Measurement
✅ Solar Park Monitoring / SCADA
✅ Dynamic Line Monitoring
✅ Adaptable and suitable for a wide range of applications
✅ Compliant with IEC 61400-12-1:2017
✅ User-friendly configuration via protected web interface
✅ Various inputs and outputs for different measurement purposes
Make

Ammonit

Model

Meteo-40S

Input Channels

Pulse Counters

4
(Anemometers, precipitation sensors)

Digital Serial (Status)

2
(Wind vanes serial, precipitation monitors, ext. activation)

Analog Voltage

4 ± 0.1V, ± 1V, ± 10V 16bit
(Barometric pressure, temperature, humidity sensors, pot. wind vanes, pyranometers, pyrheliometers )

Analog Current

1 ± 1mA, ± 10mA, ± 100mA 16bit
(Sensors with DC output, e.g., temperature humidity sensor (0 … 20mA))

RS485 (M)

(1) RS485 Master for up to 8 smart sensors
(Ultrasonic anemometers)

Output Channels

RS485 (S)

(1) RS485 Slave
(SCADA monitoring software)

5V | Switches

2
(Sensor supply, relay for modem, heating supply)

Current Source

1
(Pt1000, Pt100)

Connectivity

USB

(2) USB-A host (1) USB-B device
(PC, modem, memory stick, Ethernet, WiFi, GPS, web cam)

Ethernet

(1) Ethernet
(LAN, router, media converter, sat. modem, outdoor camera)

Storage Size

Source Data (1-sec data)

1 GB

CSV Data (10-min data)

> 50 MB

Display & Keys

(20×4) LC display with backlight, five keys

Power Supply

9 … 36 V DC

Operat. temperature

-40 … +65 °C

Protection (Housing)

IP65

Housing Dimensions

260x194x50mm

Weight

950g

Accessories

External modules, plug connector, mounting kit, steel cabinet
